Hardware Features & Performance
Model HR-CPE30A-1
Wireless Technology 802.11b/g/n 300Mbps MIMO technology
Interface LAN  1* 10/100Mbps adaptive RJ45 portDC power interface, suitable for connecting power plugs with an outer diameter of 5.5mm and an inner diameter of 2.1mm and a length of 9.5mm or more
Button Reset to factory/digital composite button, short press to adjust digital tube value, long press for 5 seconds to restore factory settings
Indicator  Light PWR power indicator light, LAN port status indicator lightSIG1/SIG2/SIG3 signal strength indicator light, digital tube
Antenna Built in dual polarized 8dBi directional plate antenna (horizontal lobe angle 90 °, vertical lobe angle 90 °)
Power supply 24V/0.5A PoE remote power supplyDC 12V/1A, external positive and internal negative
Structure Information Product Dimensions :140*75*34mmPackaging Dimensions :145*196*90mm

Product Net Weight:0.15kg

Product Gross Weight:0.65kg
Packing Information Carton Dimensions :465*310*425mmPacking Quantity: 20pair

Packing Weight: 14.06kg
Package Contents Wireless Digital Bridge*1，24V PoE power adapter * 1, plastic clamp * 2,Ethernet cable * 1, manual (including warranty card)*1
Installation Pole mounted installation
Operating Temperature -30℃～55℃
Storage Temperature -40 °C to 70 °C
Operation Humidity 10%~90%，non condensing
Storage Humidity 5%~95%，non condensing
Frequency Range 802.11b/g/n:2.4~2.4835GHz
Channel Distribution 1、2、3、4、5、6、7、8、9、10、11、12、13
Modulation Mode 802.11b: DSSS (DQPSK, DBPSK, CCK)802.11g: OFDM (BPSK, QPSK,16-QAM)

802.11n: OFDM (BPSK, QPSK,16-QAM, 64-QAM)
Transmission Speed 11b maximum 11Mbps, 11g maximum 54Mbps, 11n maximum 300Mbps
Receiving Sensitivity 11b：≤-90±1.5dBm @1Mbps，≤-84±1.5dBm @11Mbps11g：≤-86±1.5dBm @6Mbps，≤-69±1.5dBm @54Mbps

11n 20MHz：≤-85±1.5dBm @MCS0，≤-67±1.5dBm @MCS7

11n 40MHz：≤-82±1.5dBm @MCS0，≤-64±1.5dBm @MCS7
Transmission Power 11b: ≥17±1.5dBm@11Mbps11g: ≥15dBm±1.5dBm@54Mbps

11n: ≥14dBm±1.5dBm@MCS7
Transmission Distance 1km
Software Features & Performance
Working Mode Bridge access point, bridge client
Networking Method Point to point, point to many points (within eight points)
Management Style Chinese and English WEB management
State System status, bridge status, interface status
Bridge Configuration Wireless mode: Bridge access point/Bridge clientBridge access point: bridging SSID, bridging password, wireless protocol, wireless bandwidth, wireless channel, wireless power

Bridge client: bridging SSID, encryption method, bridging password, peer MAC address, wireless channel, wireless power
Network Settings Address acquisition method: automatic acquisition/static IPIP address, subnet mask, gateway, DNS1, DNS2
System Management System debugging, password modification, restart/reset/upgrade
